Electric Single Girder Overhead Crane
Lifting Capacity: 1–32 Tons
Lifting Height: 6–16 m
Span Range: 7.5–31.5 m
Duty Class: A3–A5
Working Temperature: -20°C to +40°C
Description
The Electric Single Girder Overhead Crane is a standard light to medium-duty lifting solution designed for use with CD₁ and MD₁ wire rope electric hoists. Featuring a lightweight box-type main girder and modular end carriages, this electric single girder overhead crane delivers exceptional structural rigidity, low self-weight, and cost-effective performance for manufacturing plants, warehouses, and industrial workshops.
Core Structural Features & Engineering Advantages
Engineered for optimal space utilization and reliable daily operations, key highlights include:
-
High Space Efficiency: Compact low-headroom design maximizes usable vertical workshop space while minimizing building load requirements.
-
Versatile Working Capacities: Available in load capacities from 1 to 32 tons, spans from 7.5 m to 31.5 m, and A3–A5 duty class configurations.
-
Smooth & Stable Motion: Equipped with an independent drive system to ensure quiet operation, responsive braking, and effective sway reduction.
-
Multi-Layer Safety System: Built-in overload limiters, lifting limit protection, buffer devices, under-voltage protection, and emergency stop systems.
Supported by pendant, wireless remote, or cabin controls, the electric single girder overhead crane is an ideal, energy-efficient choice for continuous intermittent material handling.
